SENDA for metal processing solutions.
5 Years
| Ask Lasest Price | |
| Brand Name : | SENDA |
| Certification : | ISO9001 |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union |
| Delivery Time : | 30-35days |
| Model Number : | SD004 |
sheet metal slitter machine rotary slitting knives for stainless steel coils and sheets
Senda Rotary slitting knives for metal coil processing are mainly applied to slitter machines. Slitting blades cut for cold milling coil, we often use LD, HMY material for thick plate and coil cutting. And hot milling coils, we often recommend to use H13, H13K, HMB material to do the slitting. With our experience, we offer the best suitable sltting blade for your slitter systems.
| Brand | Senda |
| Country of Origin | China |
| Material | D2, M2, HSS, TCT etc |
| Size: | Customized |
| Thickness tolerance | +- 0.001mm |
| Inner Diameter | +0.02mm |
| Flatness | ≤0.002mm |
| Parallelism | ≤0.002mm |
| Concentricity | ≤0.02mm |
| Surface roundness | Ra 0.1um |
| Hardness | TCT: HRA 89~93, Tool steel: HRC53~65 |
| Packaging | wooden box with anti-rust film inside |
| Application | For slitter machine, rolling mill equipment etc. |
Application of the Rotary slitting knives for metal coil processing:
1. Normally for hot rolling: 1mm~12.7mm carbon steel coils, stainless steel plates sheet etc.
2. Normally for cold rolling: 0.02mm~3.2mm carbon steel plates, stainless steel plates, galvanized plates etc.
You may also need below items:
Rotary blades
Rubber rings
Metal distance rings
Plastic spacers
Separator Discs
Clamping nuts with grease
Straight Blades
Scrap Chopping Knives
Senda starting from 1998, focus on the quality of products and provide better service. Now we have over 100 workers, CNC lathes, High precision internal and external circular grinding machines, heat-treatment furnaces grinding machines and inspection machines.
|
|
